Batteries N Bulbs
NU6-1122-PSX FOR 120V 22W FC22T9
NU6-1122-PSX FOR 120V 22W FC22T9
Regular price
$50.87 USD
Regular price
Sale price
$50.87 USD
Quantity
Couldn't load pickup availability
The NU6-1122 is a member of the Nuance 6 Specialty Line ofelectronic ballasts specially engineered to supply powerrequirements to T9 circline lamp.The NU6-1122 are instant start electronic ballasts designed tooperate one 22W T9 circline lamp in 120V applications andprovide the accurate power to the lamp to achieve it's optimaldesigned lighting output with noiseless operation. Theyfeature end-of-lamp-life auto reset protection to protect theballast in case of defective lamp and open lamp condition.This feature, allows for lamp replacement without powerinterruption.Model: NU6-1122-PSXEncapsulated in a plastic casing the size of a match box, these Nuance 6 ballast can replace almost anymagnetic ballast installed in your lighting fixtures. B+L Technologies' electronic ballasts do not requirean independent starter eliminating lamp ignition problems and flickering, and are more energy efficient. General Specifications9 Very small plastic casing9 Will power many type of lamps9 Input 120V, 277V or 347V 50/60Hz9 Instant start (120V), rapid start (277and 347V)9 High power factor >.99 UL (Class P) outdoor Type 19 End of lamp life (EOL) protection for277V and 347V models only Remote mounting: 7.6m (25ft)9 Maximum ambient temperature: 40�C9 Maximum casing temperature: 70�C (•tc)9 Minimum starting temperature: -10�C9 Ideal for infrequent on/off applications9 Can be relamped without power interruption9 Options available: Casing format RFI filter (120V only)9 Open cathode voltage: 415V9 Sound rating: A
